Frequency conversion short-stroke oscilator equipment for metal surface finishing powder coating
Frequency conversion short-stroke osicilator equipment for metal surface finishing powder coating
Effective track L Between 0.12-0.4 has 8 gears adjust
Equipment height H Body 2.6米+working track
power 3 phase 380V/50HZ
Frequency conversio 1.5KW
Recirocate speed 0.08~1.2m/second
Controller cabinet separate
Speed adjust way Frequency conversion 1.5KW
reducer Aluminum alloy RVV worm gear
Lifting roller 4pcs U-groove double row roller bearings
Lifting guide column 120×80High-precision aluminum alloy profile`
Lifting rail φ30 High rigidity linear guide
Base roller 4pcs Double bearing V-shaped roller
Cable fixing Floor type semicircular cable bracket
Gun clip φ40×40 Aluminum alloy clip
Gun rod φ38×700 Stainless steel barrel
Transmission form Crank connecting rod drive
Surface finishing Powder coating (Two color combinations
Operating temperature -10℃~50℃
Equipment height H Body 2.6米+working track
power 3 phase 380V/50HZ
Frequency conversio 1.5KW
Recirocate speed 0.08~1.2m/second
Controller cabinet separate
Speed adjust way Frequency conversion 1.5KW
reducer Aluminum alloy RVV worm gear
Lifting roller 4pcs U-groove double row roller bearings
Lifting guide column 120×80High-precision aluminum alloy profile`
Lifting rail φ30 High rigidity linear guide
Base roller 4pcs Double bearing V-shaped roller
Cable fixing Floor type semicircular cable bracket
Gun clip φ40×40 Aluminum alloy clip
Gun rod φ38×700 Stainless steel barrel
Transmission form Crank connecting rod drive
Surface finishing Powder coating (Two color combinations
Operating temperature -10℃~50℃
1. The strock can be ordered from 1 meter to 4 meters or higher.
2. The equipment is suitable for higher aluminum profiles powder spraying.
3. The equipment can be with gema powder coating guns replacement,such as optistar cg06+optigun ga02, optistar cg08+optigun ga03.
4. The oscilator also can be come with more gun details such as powder gun cable,powder transfer hose,cascade,powder spray nozzles,control unit,cabinet and so on.
We are the professional expert for pr-sales and after sales for many brands powder coating equipment such as gema,wagner and nordson.
We have more than 15 years experience to produce,sale and repair the electrostatic powder coating gun and powder machine for all over the world.
Welcome to contact us if need any help for your guns.
